Parameter Lists
4.1.5 2-** Brakes
Par. Parameter description
No. #
2-0* DC-Brake
2-00 DC Hold Current
2-01 DC Brake Current
2-02 DC Braking Time
2-03 DC Brake Cut In Speed [RPM]
2-04 DC Brake Cut In Speed [Hz]
2-05 Maximum Reference
2-06 Parking Current
2-07 Parking Time
2-1* Brake Energy Funct.
2-10 Brake Function
2-11 Brake Resistor (ohm)
2-12 Brake Power Limit (kW)
2-13 Brake Power Monitoring
2-15 Brake Check
2-16 AC brake Max. Current
2-17 Over-voltage Control
2-18 Brake Check Condition
2-19 Over-voltage Gain
2-2* Mechanical Brake
2-20 Release Brake Current
2-21 Activate Brake Speed [RPM]
2-22 Activate Brake Speed [Hz]
2-23 Activate Brake Delay
2-24 Stop Delay
2-25 Brake Release Time
2-26 Torque Ref
2-27 Torque Ramp Time
2-28 Gain Boost Factor
Table 4.8
®
VLT AutomationDrive Programmming Guide
Default value
50%
50%
10.0 s
App.Dependent
App.Dependent
MaxReference (P303)
50%
3.0 s
null
App.Dependent
App.Dependent
[0] Off
[0] Off
100.0%
[0] Disabled
[0] At Power Up
100%
ImaxVLT (P1637)
App.Dependent
App.Dependent
0.0 s
0.0 s
0.20 s
0.00%
0.2 s
1.00 N/A
®
MG33ME02 - VLT is a registered Danfoss trademark
4-set-up Change Conver-
during sion index
operation
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
Type
0 Uint8
0 Uint16
4 4
-1 Uint16
67 Uint16
-1 Uint16
-3 Int32
0 Uint16
-1 Uint16
- Uint8
0 Uint16
0 Uint32
- Uint8
- Uint8
-1 Uint32
- Uint8
- Uint8
0 Uint16
-2 Uint32
67 Uint16
-1 Uint16
-1 Uint8
-1 Uint8
-2 Uint16
-2 Int16
-1 Uint8
-2 Uint16
