Danfoss VLT AutomationDrive FC 300 Series Programming Manual page 149

Parameter Descriptions
16-85 FC Port CTW 1
Range:
0 [0 - 65535 ] View the two-byte Control word (CTW)
*
3 3
16-86 FC Port REF 1
Range:
0 [-200 -
*
200 ]
16-87 Bus Readout Alarm/Warning
Range:
0 [0 - 65535 ] Alarm and Warning numbers in hex as
*
3.17.6 16-9* Diagnosis Read-Outs
16-90 Alarm Word
Range:
0 [0 - 4294967295 ] View the alarm word sent via the serial
*
16-91 Alarm Word 2
Range:
0 [0 - 4294967295 ] View the alarm word sent via the serial
*
16-92 Warning Word
Range:
0 [0 - 4294967295 ] View the warning word sent via the
*
16-93 Warning Word 2
Range:
0 [0 - 4294967295 ] View the warning word sent via the
*
16-94 Ext. Status Word
Range:
0 [0 - 4294967295 ] Returns the extended warning word sent
*
148
VLT
Function:
received from the Bus-Master. Interpretation of
the control word depends on the Fieldbus
option installed and the Control word profile
selected in 8-10 Control Profile.
Function:
View the two-byte Status word (STW) sent to
the Bus-Master. Interpretation of the Status
word depends on the fieldbus option installed
and the Control word profile selected in
8-10 Control Profile.
Function:
displayed in the Alarm log. The High byte
contains the Alarm, the Low byte the Warning.
The Alarm number is the first one that
occurred after the last reset.
Function:
communication port in hex code.
Function:
communication port in hex code.
Function:
serial communication port in hex code.
Function:
serial communication port in hex code.
Function:
via the serial communication port in hex
code.
MG33ME02 - VLT
®
AutomationDrive Programmming Guide
16-95 Ext. Status Word 2
Range:
0 [0 - 4294967295 ] Returns the extended warning word 2
*
16-96 Maintenance Word
Range:
0 [0 -
4294967295 ]
*
®
is a registered Danfoss trademark
Function:
sent via the serial communication port
in hex code.
Function:
Readout of the Preventive Maintenance
Word. The bits reflect the status for the
programmed Preventive Maintenance Events
in parameter group 23-1*. 13 bits represent
combinations of all the possible items:
•
Bit 0: Motor bearings
•
Bit 1: Pump bearings
•
Bit 2: Fan bearings
•
Bit 3: Valve
•
Bit 4: Pressure transmitter
•
Bit 5: Flow transmitter
•
Bit 6: Temperature transmitter
•
Bit 7: Pump seals
•
Bit 8: Fan belt
•
Bit 9: Filter
•
Bit 10: Drive cooling fan
•
Bit 11: Drive system health check
•
Bit 12: Warranty
•
Bit 13: Maintenance Text 0
•
Bit 14: Maintenance Text 1
•
Bit 15: Maintenance Text 2
•
Bit 16: Maintenance Text 3
•
Bit 17: Maintenance Text 4
