13-10 Comparator Operand
Array [6]
Option:
[87] Alarm (trip lock)
3 3
[90] Bus OK
[91] Torque limit &
stop
[92] Brake fault
(IGBT)
[93] Mech. brake
control
[94] Safe stop active
[100] Comparator 0
[101] Comparator 1
[102] Comparator 2
[103] Comparator 3
[104] Comparator 4
[105] Comparator 5
[110] Logic rule 0
[111] Logic rule 1
[112] Logic rule 2
[113] Logic rule 3
[114] Logic rule 4
[115] Logic rule 5
[120] SL Time-out 0
[121] SL Time-out 1
[122] SL Time-out 2
[123] SL Time-out 3
118
®
VLT AutomationDrive Programmming Guide
Function:
[87] Alarm (trip lock) A (Trip lock) alarm
is active.
[90] Bus OK Active communication (no
time-out) via the serial communication
port.
[91] Torque limit & stop If the frequency
converter has received a stop signal and
is at the torque limit, the signal is logic
"0".
[92] Brake fault (IGBT) The brake IGBT is
short circuited.
[93] Mech. brake control The mechanical
brake is active.
[100] Comparator 0 The result of
comparator 0.
[101] Comparator 1 The result of
comparator 1.
[102] Comparator 2 The result of
comparator 2.
[103] Comparator 3 The result of
comparator 3.
[104] Comparator 4 The result of
comparator 4.
[105] Comparator 5 The result of
comparator 5.
[110] Logic rule 0 The result of Logic rule
0.
[111] Logic rule 1 The result of Logic rule
1.
[112] Logic rule 2 The result of Logic rule
2.
[113] Logic rule 3 The result of Logic rule
3.
[114] Logic rule 4 The result of Logic rule
4.
[115] Logic rule 5 The result of Logic rule
5.
[120] SL Time-out 0 The result of SLC
timer 0.
[121] SL Time-out 1 The result of SLC
timer 1.
[122] SL Time-out 2 The result of SLC
timer 2.
[123] SL Time-out 3 The result of SLC
timer 3.
MG33ME02 - VLT
13-10 Comparator Operand
Array [6]
Option:
[124] SL Time-out 4
[125] SL Time-out 5
[126] SL Time-out 6
[127] SL Time-out 7
[130] Digital input
DI18
[131] Digital input
DI19
[132] Digital input
DI27
[133] Digital input
DI29
[134] Digital input
DI32
[135] Digital input
DI33
[150] SL digital output
A
[151] SL digital output
B
[152] SL digital output
C
[153] SL digital output
D
[154] SL digital output
E
[155] SL digital output
F
[160] Relay 1
[161] Relay 2
[180] Local ref. active
[181] Remote ref.
active
[182] Start command
®
is a registered Danfoss trademark
Function:
[124] SL Time-out 4 The result of SLC
timer 4.
[125] SL Time-out 5 The result of SLC
timer 5.
[126] SL Time-out 6 The result of SLC
timer 6.
[127] SL Time-out 7 The result of SLC
timer 7.
[130] Digital input DI18 Digital input 18.
High = True.
[131] Digital input DI19 Digital input 19.
High = True.
[132] Digital input DI27 Digital input 27.
High = True.
[133] Digital input DI29 Digital input 29.
High = True.
[134] Digital input DI32 Digital input 32.
High = True.
[135] Digital input DI33 Digital input 33.
High = True.
[150] SL digital output A Use the result of
the SLC output A.
[151] SL digital output B Use the result of
the SLC output B.
[152] SL digital output C Use the result of
the SLC output C.
[153] SL digital output D Use the result
of the SLC output D.
[154] SL digital output E Use the result of
the SLC output E.
[155] SL digital output F Use the result of
the SLC output F.
[160] Relay 1 Relay 1 is active
[161] Relay 2 Relay 2 is active
[180] Local ref. active High when
3-13 Reference Site = [2] Local or when
3-13 Reference Site is [0] Linked to hand
Auto, at the same time as the LCP is in
Hand On mode.
[181] Remote ref. active High when
3-13 Reference Site= [1] Remote or [0]
Linked to hand/auto, while the LCP is in
Auto On mode.
[182] Start command High when there is
an active start command, and no stop
command.
