Transmission Cooler And Hydraulic Line Flushing Procedure; Lubrication - SSANGYONG KYRON 2010.01 Manual

5. TRANSMISSION COOLER AND HYDRAULIC LINE
FLUSHING PROCEDURE
To prevent transmission damage due to contaminants being present in the transmission
cooler and/or hydraulic lines, the cooler and lines must be flushed.
1. Raise the vehicle on a certified hoist.
2. Using compressed air, clear the cooler lines of any residual fluid.
3. Connect the front transmission cooler line to the transmission.
4. Connect one end of a rubber hose to the end of the rear cooler line and place the other end
in a suitable container to collect the transmission fluid as it is pumped out.
5.
Start the engine and run for approximately 30 seconds at idle. (With ATF at 50°C
temperature, a minimum of 2.5litres oil flow after 30 seconds.)
6. Whist the engine is running, have an assistant pump transmission fluid into the transmission
fluid level hole.
7. Connect the rear transmission cooler line to the transmission.
8. Check the transmission fluid level; refer to Fluid Level Inspection on page 69.

6. LUBRICATION

Automatic transmission fluid..................Caltex PED 1712 ATF
03-149
3680-01
DSI M78 6-SPEED A/T
KYRON 2010.01
