11. GENERAL INFORMATION OF ABS SYSTEM
Differences compared to other models: Appearance of wheel speed sensor, Location, Layout of
relevant components
ABS HECU Active Wheel Speed Sensor (for 4WD)
The transfer case (T/C) installed on this vehicle doesn't have the internal speed sensing device
and receives the speed signal for T/C control from ABS HECU.
Conventional Transfer Case
With Speed Sensor
