Maintenance Object Repair Procedures
interchange. The Processor Interface firmware can be unconditionally
downloaded to the Standby SPE circuit pack via the reset interface PCS
command, where PCS is the carrier/slot of a Standby PI. The command executes
the Standby Processor Interface Board Test (#423), but with a download option.
The Active Processor Interface circuit pack is tested in the PI-SCI (System
Communication Interface) Maintenance documentation. Refer to that section for
details. The test command is test interface PCS where PCS is the port network
number, carrier, and slot of one of the Standby Processor Interface circuit packs. If
the Standby Processor Interface circuit pack is tested, the test sequence for the
Standby Processor Interface is followed. If the Active Processor Interface circuit
pack's PCS is given, then tests in the Active Processor Interface test sequence
are run. On the Active PI, if there are no enabled Processor Interface links on the
Communication-Interface Links Form, only the XXX-BD (Common Port Circuit
Pack) tests execute.
Error Log Entries and Test to Clear Values
Table 10-458
Interface circuit packs. Since the Processor Interface circuit pack has common
port board functionalities, then cross reference XXX-BD (common port board)
maintenance information for more information. Test #423 is the only test
described in this section. XXX-BD maintenance describes the other tests
mentioned in the following table.
Table 10-458. PI-BD Error Log Entries
Error Aux
Code Data
1
0 0 Any
1 (a) 0 Circuit pack removed or
SAKI Test (#53)
23 (b) 0 None
54 (c) 0 None
124 (d) Any None
125 (e) None
257 65535 Control Channel Test
(#52)
257 (f) Any None
513 (g) Any None
769 (h) 4358 None
10-1224 Issue 4 May 2002
indicates entries that may be found in the Error Log for Processor
Associated Test
Any
MINOR
WARNI
NG
MAJOR
MAJOR
MINOR
MINOR
On/
Alarm Off
Level Board Test to Clear Value
Any test interface PCS sh r 1
ON
OFF
ON test interface PCS l
ON test interface PCS l
ON
ON test interface PCS
Continued on next page
