Specifications
This chapter presents the specifications for the adapter.
Topic

Communications

Electrical

Mechanical

Communications
Network
Protocol
Data Rates
Drive
Protocol
Data Rates
Electrical
Consumption
Drive
Network
Mechanical
Dimensions
Height
Length
Width
Weight
Page Topic
A-1 Environmental
A-1 Regulatory Compliance A-2
A-1
PROFIBUS
9.6K, 19.2K, 45.45K, 93.75K, 187.5K, 500K, 1.5M, 3M,
6M, 12M. The adapter has auto baud rate detection.
DPI
125K or 500K
370mA at 5 V supplied through the drive
19 mm (0.75 inches)
86 mm (3.39 inches)
78.5 mm (3.09 inches)
57g (2 oz.)
