Configuring the Profibus Scanner

Profibus scanners are available from several manufacturers, including
SST. Chapter 4 provides instructions on how to utilize the SST Profibus
configuration software tool to:
• Install the 20-COMM-P GSD file in the software tool library
• Configure the SST-PFB-SLC Profibus Scanner.
Topic

Example Network

Installing the 20-COMM-P GSD file in the software tool library
Configuring the SST-PFB-SLC Profibus Scanner
GSD Diagnostic Messages
Example Network
In this example, we will be configuring two PowerFlex 70 drives, to be
Station 1 and Station 2 on a Profibus network. This will be the
configuration used throughout the manual, including the ladder
examples. Apart from the node address and scanner mapping, they will
have identical configurations. This chapter describes the steps to
configure a simple network like the network in
Chapter
Page
4-1
4-3
4-5
4-19
Figure 4.1.
4
