Getting Started
1-2
Features
The PROFIBUS adapter features the following:
• The adapter is mounted in the PowerFlex drive. It receives the
required power from the drive.
• Switches let you set a node address before applying power to the
PowerFlex drive. Alternatively, you can disable the switches and use
parameters to configure this feature.
• Captive screws are used to secure the adapter to the drive.
• A number of configuration tools can be used to configure the adapter
and connected drive. The tools include the PowerFlex HIM on the
drive, or drive-configuration software such as DriveExplorer
(version 2.01 or higher) or DriveExecutive (version 1.01 or higher).
• Status indicators report the status of the drive, adapter, and network.
They are visible both when the cover is opened and when it is closed.
• I/O, including Logic Command/Reference and up to four pairs of
Datalinks, may be configured for your application using a parameter.
• Explicit messages are supported using the Parameter Protocol.
• User-defined fault actions determine how the adapter and PowerFlex
drive respond to communication disruptions on the network and
controllers in idle mode.
Compatible Products
The PROFIBUS adapter is compatible with Allen-Bradley PowerFlex
drives and other products that support DPI. DPI is a second generation
peripheral communication interface and is a functional enhancement to
SCANport. At the time of publication, compatible products include:
• PowerFlex 70 drives
• PowerFlex 700 drives
• PowerFlex 7000 drives
