B-4 Adapter Parameters
Parameter
No. Name and Description
15 [Flt Cfg A1]
16 [Flt Cfg A2]
17 [Flt Cfg B1]
18 [Flt Cfg B2]
19 [Flt Cfg C1]
20 [Flt Cfg C2]
21 [Flt Cfg D1]
22 [Flt Cfg D2]
Sets the data that is sent to the Datalink in the
drive if any of the following is true:
•
Parameter 09 - [Comm Flt Action] is set to
Send Flt Cfg and the scanner is put into
Program mode.
•
Parameter 10 - [Idle Flt Action] is set to Send
Flt Cfg and communications are disrupted.
23 [Parameter Mode]
Sets the format used when performing explicit
messages:
•
Par Prot (Parameter Protocol) is used to read
or write single parameters.
•
DPI Par Prot is reserved for future use.
Performing explicit messaging requires the
"Parameter Access" module to be added when
configuring the node with a network software tool.
24 [P-DP State]
Displays the state of the Profibus controller.
Details
Default: 0
Default: 0
Default: 0
Default: 0
Default: 0
Default: 0
Default: 0
Default: 0
Minimum: 0
Maximum: 4294967295
Type: Read/Write
Reset Required: No
Important: If the drive uses 16-bit
Datalinks, the most significant word of this
value must be set to zero (0) or a fault will
occur.
Default: 0 = Par Prot
Values: 0 = Par Prot
1 = DPI Par Prot
Type: Read/Write
Reset Required: No
Default: N/A
Values: 0 = WAIT_PRM
1 = WAIT_CFG
2 = DATA_EX
3 = ERROR
Type: Read Only
