5-8 Using I/O Messaging
The two PROFIBUS adapters are setup as Station 1 and Station 2, and
are configured as 14 words input & output each (See
SLC Data Table
Read Data
File N10: contains the actual read data that can be used elsewhere
in the ladder program.
Station 1
Address
N10:0
N10:1
N10:2
N10:3
N10:4
N10:5
N10:6
N10:7
N10:8
N10:9
N10:10
N10:11
N10:12
N10:13
Write Data
The Profibus scanner is configured for 28 bytes (14 words) of
outputs for each drive. Two drives require 48 bytes (28 words).
Station 1
Address
N20:0
N20:1
N20:2
N20:3
N20:4
N20:5
N20:6
N20:7
N20:8
N20:9
N20:10
N20:11
N20:12
N20:13
Station 2 Function
Address
N10:14 Logic Status
N10:15 Feedback
N10:16 Datalink A1
N10:17 Datalink A2
N10:18 Datalink B1
N10:19 Datalink B2
N10:20 Datalink C1
N10:21 Datalink C2
N10:22 Datalink D1
N10:23 Datalink D2
N10:24 Parameter Access Word 1
N10:25 Parameter Access Word 2
N10:26 Parameter Access Word 3
N10:27 Parameter Access Word 4
Station 2 Function
Address
N20:14 Logic Command
N20:15 Reference
N20:16 Datalink A1
N20:17 Datalink A2
N20:18 Datalink B1
N20:19 Datalink B2
N20:20 Datalink C1
N20:21 Datalink C2
N20:22 Datalink D1
N20:23 Datalink D2
N20:24 Parameter Access Word 1
N20:25 Parameter Access Word 2
N20:26 Parameter Access Word 3
N20:27 Parameter Access Word 4
Chapter 4.)
