Quick Start

This section is designed to help experienced users start using the
PROFIBUS adapter. If you are unsure about how to complete a step,
refer to the referenced chapter.
Step
1 Review the safety precautions for the adapter.
2 Verify that the PowerFlex drive is properly installed.
3 Commission the adapter.
Set a unique node address using the switches on the adapter. If
desired, you can disable the switches and use parameter
settings instead.
4 Install the adapter.
Verify that the PowerFlex drive is not powered. Then, connect
the adapter to the network using a PROFIBUS cable and to
the drive using the Internal Interface cable. Use the captive
screws to secure and ground the adapter to the drive.
5 Apply power to the adapter.
The adapter receives power from the drive. Apply power to
the drive. The status indicators should be green. If they flash
red, there is a problem. Refer to
6 Configure the adapter for your application.
Set the parameters for the following features as required by
your application:
•
Node address.
•
I/O configuration.
•
Fault actions.
7 Apply power to the PROFIBUS master and other devices
on the network.
Verify that the master and network are installed and
functioning in accordance with PROFIBUS standards, and
then apply power to them.
8 Configure the scanner to communicate with the adapter.
Use a network tool for PROFIBUS to configure the master on
the network.
9 Create a ladder logic program.
Use a programming tool to create a ladder logic program that
enables you to do the following:
•
Control the adapter and connected drive.
•
Monitor or configure the drive using Explicit Messages.
Getting Started
Chapter 7, Troubleshooting.
1-5
Refer to
Throughout
This
Manual
Drive User
Manual
Chapter 2,
Installing
the Adapter
Chapter 2,
Installing
the Adapter
Chapter 2,
Installing
the Adapter
Chapter 3,
Configuring
the Adapter
4,
Chapter
Configuring
the Profibus
Scanner
Chapter 5,
Using I/O
Messaging
Chapter 6,
Using
Explicit
Messaging
(Parameter
Protocol)
