4-2
Configuring the Profibus Scanner
Figure 4.1 Example Profibus Network
Station 0
SST Profibus Configuration Software Tool
SST Profibus scanners come with a software tool for configuring the
scanner (See
Figure 4.2 SST Profibus Configuration Software Tool
Device
Library
window
Online
Browse
window
PowerFlex 70
Station 1
Figure
4.2.)
SYS LED
COMM
LED
Config Port
Front Label
Profibus Port
PowerFlex 70
Station 2
Network
Configuration
window
