7-4 Troubleshooting

Adapter Diagnostic Items

Adapter Diagnostic Items are viewable with DriveExplorer (version 2.01
or higher), DriveExecutive (version 1.01 or higher) or HIM (2.001)
software.
No. Event
1 Common Logic
Cmd
2 Prod Logic Cmd
3 Reference
4 Common Logic
Sts
5 Prod Logic Sts
6 Feedback
7 Datalink A1 In
8 Datalink A2 In
9 Datalink B1 In
10 Datalink B2 In
11 Datalink C1 In
12 Datalink C2 In
13 Datalink D1 In
14 Datalink D2 In
15 Datalink A1 Out
16 Datalink A2 Out
17 Datalink B1 Out
18 Datalink B2 Out
19 Datalink C1 Out
20 Datalink C2 Out
21 Datalink D1 Out
22 Datalink D2 Out
23 Field Flash Cnt
24 DPI Rx Errors
25 DPI Tx Errors
26 PbusImage Siz
27 Switch 0
28 Switch 1
Description
The current value of the Common Logic Command being transmitted
to the host.
The current value of the Product-specific Logic Command being
transmitted to the host.
The current value of the Product-specific Reference being
transmitted to the host.
The current value of the Common Logic Status being received from
the host.
The current value of the Product-Specific Status being received from
the host.
The current value of the Product-Specific Feedback being received
from the host.
The current value of Datalink A1 being transmitted to the host.
(Value of 0 if datalink is not used).
The current value of Datalink A2 being transmitted to the host.
(Value of 0 if datalink is not used).
The current value of Datalink B1 being transmitted to the host.
(Value of 0 if Datalink is not used).
The current value of Datalink B2 being transmitted to the host.
(Value of 0 if Datalink is not used).
The current value of Datalink C1 being transmitted to the host.
(Value of 0 if Datalink not used).
The current value of Datalink C2 being transmitted to the host.
(Value of 0 if Datalink is not used).
The current value of Datalink D1 being transmitted to the host.
(Value of 0 if Datalink is not used).
The current value of Datalink D2 being transmitted to the host.
(Value of 0 if Datalink is not used).
The current value of Datalink A1 being received from the host.
The current value of Datalink A2 being received from the host.
The current value of Datalink B1 being received from the host.
The current value of Datalink B2 being received from the host.
The current value of Datalink C1 being received from the host.
The current value of Datalink C2 being received from the host.
The current value of Datalink D1 being received from the host.
The current value of Datalink D2 being received from the host.
The number of times this device has been flash updated.
The current value of the DPI CAN Receive error counter.
The current value of the DPI CAN Transmit error counter.
Buffer size of Active I/O image (Profibus size) in bytes.
The value of Switch 0. (Node Address 1's digit)
The value of Switch 1. (Node Address 10's digit)
