Port Status Indicator - Allen-Bradley PowerFlex 20-COMM-P FRN 1 Series User Manual

7-2 Troubleshooting
ti

PORT Status Indicator

Status Cause
Off The adapter is not powered
or is not connected
properly to the drive.
Flashing Red The adapter is not
receiving a ping message
from the drive.
Solid The drive has refused an
Red I/O connection from the
adapter.
Another DPI peripheral is
using the same DPI port as
the adapter.
Orange The adapter is connected
to a product that does not
support Allen-Bradley DPI
communications.
Flashing Green The adapter is establishing
an I/O connection to the
drive.
Solid Green The adapter is properly
connected and is
communicating with the
drive.
Corrective Action
•
Securely connect the adapter to the drive
using the ribbon cable.
•
Apply power to the drive.
•
Verify that cables are securely connected.
•
Cycle power to the drive.
Important: Cycle power to the product after
making any of the following corrections.
•
Verify that all DPI cables on the PowerFlex
drive are securely connected and not
damaged. Replace cables if necessary.
•
Verify that the PowerFlex drive supports
Datalinks.
•
Configure the adapter and PowerFlex drive
to use a Datalink that is not already being
used by another peripheral.
•
Connect the adapter to a product that
supports Allen-Bradley DPI communications
(for example, PowerFlex drives).
•
No Action. This status indicator will turn solid
green or red.
•
No Action.
