Reading Parameter 140 [Accel Time 1] from the PowerFlex 70
(DPI Port 0)
Command
Reply
Reading Parameter 4 [P-DP Addr Actual] from the 20-COMM-P on a
PowerFlex 70 (DPI Port 5)
Command
Reply
Using Explicit Messaging (Parameter Protocol)
1000 hex = Read
1
108C
8C hex = 140 dec (Pr. 140)
2
0 DPI Port 0 (DPI Host)
3
0
Not Used
Not Used
4 0
Transferring 16-bit parameter value ("1")
1
108C
Confirms Par. Number of the request ("8C")
2 Confirms Par. Access Word 2 of the request
0
(DPI Port #)
0
3
Not Used
4 32 hex = 50 dec = 5.0 seconds
32
1000 hex = Read
1
1004
4 hex = 4 dec (Pr. 4)
2
5
DPI Port 5 (20-COMM-P)
3
0
Not Used
4 0
Not Used
Transferring 16-bit parameter value ("1")
1
1004
Confirms Par. Number of the request ("4")
2 Confirms Par. Access Word 2 of the request
5
(DPI Port #)
0 Not Used
3
4
1 hex = 1 dec = Station 1
1
6-7
