Chapter 2: Board Components
Configuration, Status, and Setup Elements
Table 2–9. Board-Specific LEDs (Part 2 of 2)
Board Reference
LED Name
D29, D30, D31
PROGRAM
(PGM_LED[2:0])
D22
ENET TX
D18
ENET RX
D20
10
D16
100
D15
1000
D2
HSMA PRSNTn
D1
HSMB PRSNTn
D4
USB
Table 2–10
information.
Table 2–10. Board-Specific LEDs Component References and Manufacturing Information
Board Reference
D1, D2, D4, D7,
D11-D16, D18, D20,
D22, D29-D31
D10
D3

Setup Elements

The development board includes several different kinds of setup elements. This
section describes the following setup elements:

Board Settings DIP Switch

The board settings DIP switch (SW2) controls various features specific to the board
and the MAX II CPLD EPM2210 System Controller logic design.
switch controls and descriptions.
© October 2009 Altera Corporation
Green LEDs. Illuminates to show the LED sequence that determines which flash
memory image loads to the FPGA when PGM select push-button switch is
pressed. Driven by the MAX II CPLD EPM2210 System Controller.
Green LED. Illuminates to indicate Ethernet PHY transmit activity. Driven by the
Marvell 88E1111 PHY.
Green LED. Illuminates to indicate Ethernet PHY receive activity. Driven by the
Marvell 88E1111 PHY.
Green LED. Illuminates to indicate Ethernet linked at 10 Mbps connection speed.
Driven by the Marvell 88E1111 PHY.
Green LED. Illuminates to indicate Ethernet linked at 100 Mbps connection speed.
Driven by the Marvell 88E1111 PHY.
Green LED. Illuminates to indicate Ethernet linked at 1000 Mbps connection
speed. Driven by the Marvell 88E1111 PHY.
Green LED. Illuminates when HSMC port A has a board or cable plugged-in such
that pin 160 becomes grounded. Driven by the add-in card.
Green LED. Illuminates when HSMC port B has a board or cable plugged-in such
that pin 160 becomes grounded. Driven by the add-in card.
Green LED. Illuminates when the embedded USB-Blaster is in use to program the
FPGA. Driven by the MAX II CPLD EPM2210 System Controller and MAX IIZ.
lists the board-specific LEDs component references and manufacturing
Description
Manufacturer
Green LEDs
Lumex, Inc.
Red LED
Lumex, Inc.
Blue LED
Lumex, Inc.
Board settings DIP switch
JTAG chain header switch
Configuration push-button switches
Description
Manufacturer Part Number
SML-LX1206GC-TR
SML-LX1206IC-TR
SML-LX1206USBC-TR
Cyclone III LS FPGA Development Board Reference Manual
2–17
Manufacturer Website
www.lumex.com
www.lumex.com
www.lumex.com
Table 2–11
