Altera Cyclone III LS Reference Manual page 39

Chapter 2: Board Components
Components and Interfaces
Table 2–34. HSMC Port A Pin Assignments, Schematic Signal Names, and Functions (Part 2 of 3)
Board
Reference
J2.83 LVDS TX bit 6 or CMOS bit 28
J2.84 LVDS RX bit 6 or CMOS bit 29
J2.85 LVDS TX bit 6n or CMOS bit 30
J2.86 LVDS RX bit 6n or CMOS bit 31
J2.89 LVDS TX bit 7 or CMOS bit 32
J2.90 LVDS RX bit 7 or CMOS bit 33
J2.91 LVDS TX bit 7n or CMOS bit 34
J2.92 LVDS RX bit 7n or CMOS bit 35
J2.95 LVDS or CMOS clock out 1 or CMOS bit 36
J2.96 LVDS or CMOS clock in 1 or CMOS bit 37
J2.97 LVDS or CMOS clock out 1 or CMOS bit 38
J2.98 LVDS or CMOS clock in 1 or CMOS bit 39
J2.101 LVDS TX bit 8 or CMOS bit 40
J2.102 LVDS RX bit 8 or CMOS bit 41
J2.103 LVDS TX bit 8n or CMOS bit 42
J2.104 LVDS RX bit 8n or CMOS bit 43
J2.107 LVDS TX bit 9 or CMOS bit 44
J2.108 LVDS RX bit 9 or CMOS bit 45
J2.109 LVDS TX bit 9n or CMOS bit 46
J2.110 LVDS RX bit 9n or CMOS bit 47
J2.113 LVDS TX bit 10 or CMOS bit 48
J2.114 LVDS RX bit 10 or CMOS bit 49
J2.115 LVDS TX bit 10n or CMOS bit 50
J2.116 LVDS RX bit 10n or CMOS bit 51
J2.119 LVDS TX bit 11 or CMOS bit 52
J2.120 LVDS RX bit 11 or CMOS bit 53
J2.121 LVDS TX bit 11n or CMOS bit 54
J2.122 LVDS RX bit 11n or CMOS bit 55
J2.125 LVDS TX bit 12 or CMOS bit 56
J2.126 LVDS RX bit 12 or CMOS bit 57
J2.127 LVDS TX bit 12n or CMOS bit 58
J2.128 LVDS RX bit 12n or CMOS bit 59
J2.131 LVDS TX bit 13 or CMOS bit 60
J2.132 LVDS RX bit 13 or CMOS bit 61
J2.133 LVDS TX bit 13n or CMOS bit 62
J2.134 LVDS RX bit 13n or CMOS bit 63
J2.137 LVDS TX bit 14 or CMOS bit 64
J2.138 LVDS RX bit 14 or CMOS bit 65
© October 2009 Altera Corporation
Description
Schematic Signal
Name
HSMA_TX_P6
HSMA_RX_P6
HSMA_TX_N6
HSMA_RX_N6
HSMA_TX_P7
HSMA_RX_P7
HSMA_TX_N7
HSMA_RX_N7
HSMA_CLKOUT_P1
HSMA_CLKIN_P1
HSMA_CLKOUT_N1
HSMA_CLKIN_N1
HSMA_TX_P8
HSMA_RX_P8
HSMA_TX_N8
HSMA_RX_N8
HSMA_TX_P9
HSMA_RX_P9
HSMA_TX_N9
LVDS or 2.5-V
HSMA_RX_N9
HSMA_TX_P10
HSMA_RX_P10
HSMA_TX_N10
HSMA_RX_N10
HSMA_TX_P11
HSMA_RX_P11
HSMA_TX_N11
HSMA_RX_N11
HSMA_TX_P12
HSMA_RX_P12
HSMA_TX_N12
HSMA_RX_N12
HSMA_TX_P13
HSMA_RX_P13
HSMA_TX_N13
HSMA_RX_N13
HSMA_TX_P14
HSMA_RX_P14
Cyclone III LS FPGA Development Board Reference Manual
(1)
Cyclone III LS
Device
I/O Standard Pin Number
V23
G25
V24
F25
V25
G27
W26
G28
V28
AG16
U28
AH16
W24
H26
W25
G26
AA26
J27
Y26
J28
AA27
K27
AA28
K28
AB27
J25
AB28
J26
AD28
M26
AC28
M27
AA25
K25
AB26
K26
AF28
L24
2–31
