2–20
Table 2–18
and manufacturing information.
Table 2–18. LCD/HSMB Data Select Header Switch Component Reference and Manufacturing Information
Board Reference
J18 2x1 100 mil jumper

Configuration Push-button Switches

The PGM configure push-button switch, PGM_CONFIG (S8), is an input to the MAX II
CPLD EPM2210 System Controller. The push-button switch forces a reconfiguration
of the FPGA from flash memory. The location in the flash memory is based on the
PGM_LED[2:0] setting when the button is released. Valid settings include
PGM_LED0, PGM_LED1, or PGM_LED2 illuminated. There are three pages in flash
memory reserved for FPGA designs.
The PGM select push-button switch, PGM_SEL (S9), toggles the program LEDs (D29,
D30, D31) sequence. Refer to
definitions.
The CPU reset push-button switch, CPU_RESETn (S2) is a dedicated reset switch for
the embedded processors which is wired to the FPGA DEV_CLRn pin, while the MAX
II reset push-button switch, MAX_RESETn (S10), resets the MAX II CPLD EPM2210
System Controller.
Table 2–19
manufacturing information.
Table 2–19. Configuration Push-button Switches Component Reference and Manufacturing Information
Board Reference
S2, S8, S9, S10 Push-button switch

Clock Circuitry

This section describes the board's clock inputs and outputs.

Cyclone III LS FPGA Clock Inputs

Figure 2–6
Cyclone III LS FPGA Development Board Reference Manual
lists the LCD/HSMC port B data select header switch component reference
Description Manufacturer
lists the configuration push-button switches component reference and
Description Manufacturer
Panasonic
shows the Cyclone III LS FPGA development board clock inputs.
Manufacturer
Part Number
3M/ESD 929665-09-36-I
Table 2–8 on page 2–16
Manufacturer
Part Number
EVQPAC07K
Chapter 2: Board Components
Clock Circuitry
Manufacturer Website
www.3m.com
for the PGM_LED[2:0] sequence
Manufacturer Website
www.panasonic.com/industrial/
