C H A P T E R 5 – G E T T I N G
The next section of the Tutorial demonstrates running the program on the AT5600
tester from the Server store.
Before proceeding to that section, if the Server and Editor are using the same
COM-Port on the single PC, re-allocate the COM-Port from the Editor to the
Server:
1. Close down the Editor by clicking on 'Part' menu, select 'Exit from the
Top Level.
2. Start the Server by double clicking on its Windows icon.
3. Configure the COM-Port for the Server.
4. Remove the cable between the AT Auxiliary Port and the PC COM-
Port.
5. Connect the cable between the AT Server Port and the PC COM-Port.
1. Start the Server program by double-clicking with the left mouse button on the
Server icon.
Ensure the communication port is set up by clicking on 'Setup menu, select
'Communications from the Top Level. The configure server communication
dialog box will now appear;
Add the Com Port assign to the server port to the open channel window, and
then click Close.
2. Loading a program from the server:
A full description of the Front Panel operation is given in Chapter 8.
Using the front panel of the AT5600, from the top-level menu, tap the soft-key
EXECUTE to change to the following display:
