Voltech AT5600 User Manual page 383

C H A P T E R 1 6 - C H A N G E
If successful, a new results window will be displayed as shown in Error! R
eference source not found.. The title bar of the results window shows which
testers results will be shown in this window (in this case, "AT on COM1"). The
Server software is now ready to communicate with the AT tester.
NOTE: So far no communications will have taken place with the unit. To
confirm it is set up correctly, communications must be tested from the AT
series tester.
Highlight the open channel, and then click the Remove button in to remove the
open channel and close the results window.
AT5600 User Manual 98-119 issue 14
L O G
Page 383
