C H A P T E R 1 0 – S P E C I F I C A T I O N S
10.3.7.
The Ethernet port is a standard RJ45 8P8C connector that provides a standard
10/100 Ethernet interface.
10.3.8.
Standard USB 2.0 type 'A' interfaces used to connect the AT5600 to a printer.
10.3.9.
A standard USB 2.0 type 'B' interface used to connect the AT5600 to a PC
running the Voltech editor software.
AT5600 User Manual 98-119 issue 14

Ethernet Port

Front and Rear USB 'A' Ports

USB 'B' Port

Page 248
