C H A P T E R 1 3 – T E S T
13.5.1.
Description
Continuity
DC Resistance
DC Resistance Match
Inductance (Series circuit)
Inductance (Parallel circuit)
Inductance Match
Inductance with Bias (Series)
Inductance with Bias (Parallel)
Impedance with Bias
Inductance with External Bias (Series)
Inductance with External Bias (Parallel)
Impedance with External Bias
Quality Factor
Dissipation Factor
Equivalent Series Resistance
Equivalent Parallel Resistance
Impedance
Impedance Phase Angle
Leakage Inductance
Inter-winding Capacitance
Inter-winding Capacitance Match
Turns Ratio and Phasing by Voltage
Turns Ratio and Phasing by Inductance
Low open Circuit Voltage
Inter-winding Phase
Insertion Loss
Return Loss
Longitude Balance
General Longitude Balance
Frequency Response
Magnetizing Current
Open Circuit Voltage
Wattage
Stress Wattage
Magnetizing Current (External Source)
Open Circuit Voltage (External Source)
Wattage (External Source)
Stress Wattage (External Source)
Leakage Current
Insulation Resistance
Hi-Pot (DC)
Hi-Pot (AC)
Hi-Pot Ramp (DC)
Hi-Pot Ramp (AC)
Voltage Break down (DC)
Voltage Break down (AC)
Surge Stress
Output to User Port
AT5600 User Manual 98-119 issue 14
F I X T U R E S
Compensation Summary – Available Tests
TEST
Mnemonic
CTY
R
R2
LS
LP
L2
LSB
LPB
ZB
LSBX
LPBX
ZBX
QL
D
RLS
RLP
Z
ANGL
LL
C
C2
TR
TRL
LVOC
PHAS
ILOS
RLOS
LBAL
GBAL
RESP
MAGI
VOC
WATT
STRW
MAGX
VOCX
WATX
STRX
ILK
IR
HPDC
HPAC
DCRT
ACRT
DCVB
ACVB
SURG
OUT
COMPENSATION AVAILABLE?
S/C O/C
Yes No
Yes No
Yes No
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
No Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
No Yes
No Yes
No Yes
No Yes
No No
No No
No No
No No
No Yes
No Yes
No Yes
No Yes
No Yes
No Yes
No Yes
No Yes
No No
No No
Load
No
No
No
No
No
No
No
No
No
No
No
No
No
No
No
No
No
No
Yes
No
No
No
No
No
No
No
No
No
No
No
No
No
No
No
No
No
No
No
No
No
No
No
No
No
No
No
Yes
No
Page 265
