C H A P T E R
1 6
-
C H A N G E
What follows is an example of the first part of a batch result file.
Note the DOS file name (c6200697.atr) and the part name ("Part #" "2") are both
listed within the file.
"VOLTECH AT5600 RESULTS FILE"
"Server Program Version: 2.1"
"Communication Channel: 6"
"AT5600 ID: 0571"
"AT5600 Software Version: 2.2"
"File name: C6200697.atr"
"Test Date: 20 Jun 1997"
"Part #","2"
"Fixture ID","TEST"
"Operator"
"Batch #"
"No Fixture Compensation"
"Result #","Serial #","Time", "Pass/Fail","","001
"","","","","","Minimum","Maximum","Reading","","Minimum","Maximum","R
1,"","10:44:20","Pass","",59,73,6.776850E+01,"Pass",3,,3.223899E+00,"P
2,"","10:44:23","Pass","",59,73,6.776832E+01,"Pass",3,,3.110549E+00,"P
3,"","10:44:24","Pass","",59,73,6.776363E+01,"Pass",3,,3.125640E+00,"P
4,"","10:44:26","Pass","",59,73,6.777967E+01,"Pass",3,,3.135034E+00,"P
5,"","10:44:27","Pass","",59,73,6.777842E+01,"Pass",3,,3.185198E+00,"P
6,"","10:44:29","Pass","",59,73,6.778374E+01,"Pass",3,,3.152627E+00,"P
...and so forth for each result until a change of batch or part. If a result window is
closed, the connection to the transformer tester will be lost. A warning is issued
before connections are removed.
15.5.2.
Four approaches have been provided to allow observation of your test result data:
On-Line monitoring
On-Line analysis via a Database
On-Line analysis via OLE
Off-Line analysis
AT5600 User Manual 98-119 issue 14
L O G

Result Display and Analysis

R","","","","002
Page 393
