1 4 . 5 . 1 2 . 3 T e s t G r o u p i n g
Tests can be programmed in any order you wish, and the results for each individual test
will be independent of where they are in the program.
However, the AT5600 has 6 different power sources, and to get the best speed
execution time we recommend that tests are grouped using the following table.
This minimizes change over time between the different sources.
Please note that the table and "Best Speed Grouping" column does not indicate any
overall ORDER for the tests, just the best grouping.
Tests in the same group can be run in any order, and the groups can be run in any order
(e.g. most customers always start with R to check windings)
For example
LS
would execute faster than
LS
as HPAC is in a different grouping from the other 3
Or
R
would execute faster than
R
as MAGI and VOC are in the same group.
Test Test Description
ANGL Impedance Phase Angle
D Dissipation Factor
L2 Inductance Match
LL Leakage Inductance
LP Parallel Inductance
LS Series Inductance
QL Quality Factor
RLP Equivalent Parallel Resistance
RLS Equivalent Series Resistance
TRL Turns Ratio By Inductance
Z Impedance
LPB Parallel Inductance with Bias
LSB Series Inductance with Bias
ZB Impedance with bias
LVOC Low Voltage Open Circuit
PHAS Interwinding Phase Angle
TR Turns Ratio
AT5600 User Manual 98-119 issue 14
E D I T O R
RLP Z HPAC
HPAC RLP Z
LS RLS MAGI VOC
LS MAGI RLS VOC
Best Speed Grouping
A
A
A
A
A
A
A
A
A
A
A
B
B
B
C
C
C
