C H A P T E R 1 0 – S P E C I F I C A T I O N S
Notes:
1 A = the basic relative accuracy (see later for the full specification).
R
2 Depends on external source type.
3 650 Vrms for AC measurements, or 900 V for DC measurements.
Note: 25W MAX for VOC/MAGI/WATT/STRW.
4 Peak value
5 DC bias current accuracy is +/-10% of the requested value.
Test Frequency Accuracy
F <= 16 kHz
F >16 kHz and <= 250kHz
F > 250 kHz
Signal Level Accuracy
Voltage
Current:
Tests in BOLD
MAGX VOCX WATX STRX
LSBX LPBX ZBX
AT5600 User Manual 98-119 issue 14
error is +/-0.25Hz +/- 0.01% of requested frequency.
error is +/- 4Hz +/- 0.01% of requested frequency.
error is +/- 64 Hz +/- 0.01% of requested frequency.
+/- 1mV +/- (2.5% +/- 0.01% / kHz) of test signal.
+/- 100 uA +/- (2.5% +/- 0.01% / kHz) of test signal.
- for use with AC INTERFACE.
- for use with DC1000 / DC1000A.
