Continuity
R
DC Winding Resistance
R2
Resistance Match
MAGI
Magnetizing Current
STRW
Stress Wattage
VOC
Open Circuit Voltage
WATT
Wattage
C
Interwinding Capacitance
C2
Capacitance Match
MAGX
Magnetising Current (AC Interface)
STRX
Stress Wattage (AC Interface)
VOCX
Open Circuit Voltage (AC Interface)
WATX
Wattage (AC Interface)
LPBX
Parallel Inductance with Bias (DC1000)
LSBX
Series Inductance with Bias (DC1000)
ZBX
Impedance with Bias (DC1000)
ILOS
Insertion Loss
LBAL
Longitudinal Balance
RESP
Frequency Response
RLOS
Return Loss
GBAL
General Longitudinal Balance
ACRT
Hi-Pot Ramp AC
ACVB
Hi-Pot Voltage Breakdown AC
DCRT
Hi-Pot Ramp DC
DCVB
Hi-Pot Voltage Breakdown DC
HPAC
Hi-Pot AC
HPDC
Hi-Pot DC
ILK
Leakage Current
IR
Insulation Resistance
SURG
Surge Stress
