C H A P T E R 1 0 – S P E C I F I C A T I O N S
10.3.4.
This interface is for connection only to an approved Voltech accessory.
Do not try to make other connections to this interface as damage may occur.
15-pin female D-type connector
Pin
1 o/p
2 o/p
3 o/p
4 o/p
5 o/p
6
7
8 i/p
HP_OUT Pin 14
DANGEROUS voltage up to 400V can be present on the HP_OUT pin when any
attached safety device signals a safe condition.
General Signal Pins
Except for the HP_OUT pin, the other signals are either digital TTL type outputs
or inputs, or connections through to the internal power supplies and signal
generator sources.
AT5600 User Manual 98-119 issue 14

Peripheral Interface

Signal name
CC
LP_LO
+12V
ENAUX
AUX_RELAY
0V(HP)
No connection
AUX_IN
Pin Signal name
9 o/p LP_HI
10 No connection
11 i/p AUXTRIP\
12 No connection
13 0V(AUX)
14 o/p HP_OUT
15 No connection
