C H A P T E R 1 6 - C H A N G E
Table:
Field
ResultID
RunID
TestID
TestNo
OC_Comp
SC_Comp
Load_Comp
Result
TestStatus
PassFail
Table:
Field
TestID
TestMnemonic
TestUnits
CheckType
MinLimit
MaxLimit
* Notes:
(CheckType = NONE)
(CheckType = MIN)
(CheckType = MAX)
(CheckType = DIFF)
(CheckType = POL)
If Positive Polarity test, MinLimit = 0 and MaxLimit = 1
If Negative Polarity test, MinLimit = -1 and MaxLimit = 0
AT5600 User Manual 98-119 issue 14
L O G
tblVoltechResults
Format Notes
Text (25) Index ID
Text (25) As tblVoltechRunID.RunID
Text (25) As tblVoltechTestID.TestID
Number Test number as in test program
(Long Integer)
Text (5) YES, NO, N/A
Open Circuit Compensation status
Text (5) YES, NO, N/A
Short Circuit Compensation status
Text (5) YES, NO, N/A
Load Compensation (future
development)
Number (Single) Actual test result
Text (5) DSP Status for test
Text (5) PASS/FAIL
Individual test pass or fail result
tblVoltechTestID
Format Notes
Text (25) Index ID
Text (10) Individual test mnemonic
Text (10) Individual test units
Text (5) NONE/MIN/MAX/DIFF/POL
Type of test limits (see *)
Number (Single) Minimum limit for test (see *)
Number (Single) Maximum limit for test (see *)
If there are no Min or Max limits,
MinLimit = 0 and MaxLimit = 0
If there is a Min limit only, MaxLimit = 0
If there is a Max limit only, MinLimit = 0
If there is a Min and Max limit
Polarity test
