C H A P T E R
1 6
-
C H A N G E
R CTY
Increased the current ranges for DCR range combinations to reduce
the decrease the probability of 0002 error codes.
R CTY
Improved the low impedance detection on high DC resistance range
combinations.
R CTY
Resistance ranges and signal levels have been adjusted to give
improved accuracy, particularly around 100 ohms.
TRL L2
Improved the trimming algorithm for TRL and L2 to reduce the effect of
limits on the measured value when in auto mode.
VOC
Improved noise rejection for VOC tests by utilizing harmonic analysis.
(ID 9515)
VOCX WATX MAGX
VOCX to dramatically increase execution speed.
VOCX WATX MAGX
for MAGX, WATX and VOCX tests when used with AT output + Transformer
VOCX WATX MAGX
when the signal level or frequency changes. ESE is enabled for all sequential AC IF
tests.
AT5600 User Manual 98-119 issue 14
L O G
Improved the execution sequence for MAGX, WATX and
Added class D current limiting to the energization process
External magnetizing tests no longer disable ESE even
Page 429
