COPPER SPECIFICATIONS
Transmitter characteristics
Receiver characteristics
POTS dialer
Digital multimeter (DMM)
NOTES
a. Subject to change without notice.
b. Typical, at 23 °C ± 3 °C, on batteries, with no type B USB connection.
c. Specifications based on 24 AWG (PE 0.5 mm) cabling.
d. From 10 mA to 110 mA.
MaxTester Copper Test
a, b, c
Frequency range (200 Hz to 20 kHz) Frequency resolution
Frequency uncertainty (accuracy)
Level range (dBm)
Level resolution
Level uncertainty (accuracy)
Impedance ( )
Frequency range (20 kHz to 2.2 MHz) Frequency resolution
Frequency uncertainty (accuracy)
Level range (dBm)
Level resolution
Level uncertainty (accuracy)
Impedance ( )
Frequency range (2.2 MHz to 30 MHz) Frequency resolution
Frequency uncertainty (accuracy)
Level range (dBm)
Level resolution
Level uncertainty (accuracy)
Impedance ( )
Reception frequency range
Frequency uncertainty range (accuracy)
VF reception level range (dBm)
VF level uncertainty (accuracy)
WB reception level range (dBm)
WB level uncertainty (accuracy)
Impedance ( )
DTMF
Phonebook
Test type
Impedance selection (for voltage measurement)
Measurement
DC voltage
AC voltage
Isolation resistance
(stress/leakage)
Resistance
Capacitance
DC current
AC current
Station Ground
I
MPORTANT
1-Hz steps
±(50 ppm + 1 Hz)
–20 to 10 at 600
0.1 dB
±1 dB
600
1-kHz steps
±(50 ppm + 100 Hz)
–20 to 10 at 100
0.1 dB
±1 dB
100, 120, 135, 150
1-kHz steps
±(50 ppm + 100 Hz)
–20 to 0 at 100
0.1 dB
±1 dB
100, 120, 135, 150
200 Hz to 20 kHz
20 kHz to 30 MHz
±(50 ppm + 1 digit)
–90 to 15 at 600
200 Hz to 20 kHz
–90 dBm to –50 dBm, uncertainty (accuracy) ±2 dB
–50 dBm to 15 dBm, uncertainty (accuracy) ±1 dB
–90 to 15 at 100
20 kHz to 2.2 MHz
–90 dBm to –50 dBm, uncertainty (accuracy) ±2 dB
–50 dBm to 15 dBm, uncertainty (accuracy) ±1 dB
2.2 MHz to 30 MHz
–90 dBm to –50 dBm, uncertainty (accuracy) ±2 dB
–50 dBm to 15 dBm, uncertainty (accuracy) ±1 dB
100, 120, 135, 150, 600
0 – 9, #, *
25 entries
Snapshot and continuous
100 k , 1 M
Range Resolution
0 to 400 V 0.1 V for 0 to 99.9 V
1 V for 100 V to 400 V
0 to 280 Vrms 0.1 V for 0 to 99.9 V
1 V for 100 V to 280 V
0 to 1 G , auto-ranging Three digits
1 k to 99 M
100 M to 999 M
0 to 100 M Three digits
0 to 999
1 k to 100 M
0.1 nF to 2 μF Four digits
0 to 110 mA 0.1 mA
0 to 110 mA 0.1 mA
0 to 1 M Up to three digits
0 to 999
1 k to 1 M
and 135
Uncertainty (accuracy)
±(|1 %| + 0.5 VDC)
±(1 % + 0.5 VAC)
±(2 % + 1 digit)
±(5 % + 1 digit)
±(1 % + 5 )
±(2 % + 1 digit)
±(2 % + 50 pF)
±(|2 %| + 1 mA)
d
±(|2 %|+ 1 mA)
±(1 % + 3 )
±(2 % + 1 digit)
