Result displays the distance to the most significant reflection.

Test Status displays the current state of measurement or an error

message.
To select the parameter values:
1. Press the up/down arrow keys to highlight the desired parameter.
2. Press the left/right arrow keys to view and select the options.
OR
3. Press
4. Press
MaxTester Copper Test
Pan - use left/right arrow keys to pan the x-axis and the up/down
arrow keys to pan the y-axis.
1:1 resets the x-axis and y-axis limits to full scale.
Return To Test removes these function keys and displays the
Continuous page.
on a value to open a list box of options.
to confirm the value.
SmartR™ Features
Pair Detective
