Test Status displays the current state of measurement or an error

message.
Load Trace function key opens a new page that allows you to load a

trace from a list of previously saved TDR tests
Clear Trace function key deletes the loaded trace from the graph.

Landscape Mode function key allows you to view the test results in

landscape mode. Rotating the unit clockwise or counter-clockwise
and having the keyboard on the right or left is dependent on your
preferred Landscape Mode Settings configured in Application
Settings/General.
This mode generates the following function keys:


MaxTester Copper Test
Portrait Mode is used to change the screen orientation from
landscape to portrait.
Select Graph opens a new selection of function keys which allow
you to maneuver the graph. (Same as above.)
