Technical Specifications
COPPER SPECIFICATIONS
Isolation resistance
(stress/leakage) (continued)
VF noise measurement
VF impulse noise
Power influence (noise to ground)
VF longitudinal balance
Time-domain reflectometer (TDR)
Load coil detection
Near-End Crosstalk (NEXT)
NOTES
a. Subject to change without notice.
b. Typical, at 23 °C ± 3 °C, on batteries, with no type B USB connection.
c. Specifications based on 24 AWG (PE 0.5 mm) cabling.
d. Qualified up to 300 m (1000 ft) and does not include the uncertainty due to VOP.
266
a, b, c
(continued)
Source
Soak timer (s)
Frequency range
Level range (dBm)
Resolution (dB)
Uncertainty (accuracy)
Filters
Impedance
Low threshold (dBm)
Mid threshold
High threshold
Separation (dB)
Dead time (ms)
Filters
Counter
Timer
Noise range (dBm)
Uncertainty (accuracy)
Frequency (Hz)
Level range (dB)
Level uncertainty (accuracy) (dB)
Impedance
Modes
Distance range (m)
Pulse width
Amplitude
Velocity of propagation (VOP)
d
Distance uncertainty (accuracy) (m)
Units
Count
Plot (kHz)
Distance range (m)
Frequency Range
Level Range
Level Resolution
Level uncertainty (accuracy)
Terminations
50 to 125 VDC (current safely limited to 0.5 mA)
1 to 60
200 Hz to 20 kHz
–90 to 20
0.1
–90 dBm to –50 dBm, uncertainty (accuracy) ±2 dB
–50 dBm to +20 dBm, uncertainty (accuracy) ±1 dB
ITU: none, psophometric, P-notched, 3.4 kHz, D-filter, 15 kHz
ANSI: none, C-message, C-notched, 3.4 kHz, D-filter, 15 kHz
600
–40 to 0, in 1 dB steps
Low threshold plus separation
Mid threshold plus separation
1 to 6, in 1 dB steps
125
None, 3 kHz flat, C-message, psophometric,
notched and D filter (IEEE 743-1995)
Maximum 999 for each threshold
Maximum 100 hours
–60 to 10
–60 dBm to –50 dBm ± 2 dB
–50 dBm to 10 dBm ± 1 dB
1004
0 to 100
±1
600
Fully automatic operation with location of most significant event(s)
0 to 6700 (0 ft up to 22 000 ft)
15 ns to 20 μs
7.5 V p-p on cable, 9 V p-p open circuit
0.400 to 0.999
±(0.5 m + 1 % x distance)
Meters and feet
Up to 5
Up to 10
Up to 8000 (up to 27 000 ft)
10 kHz to 30 MHz
0 to 90 dB
0.1 dB
2.2 MHz: ±2.0 dB, from 0 to 90 dB
8 MHz: ±2.0 dB, from 0 to 80 dB
12 MHz: ±2.0 dB, from 0 to 75 dB
17.6 MHz: ±3.0 dB, from 0 to 75 dB
30 MHz: ±3.0 dB, from 0 to 68 dB
100, 120, 135, 150
