A Technical Specifications
The following technical specifications can change without notice.
The information presented in this section is provided as a reference
only. To obtain this product's most recent technical specifications,
visit the EXFO Web site at www.exfo.com.
WAVELENGTH
Range (nm)
Display resolution (pm)
Effective spectral linewidth FWHM
c
Repeatability (pm)
Stability c (pm)
Uncertainty d (pm)
e
Sweep rate (nm/s)
Tuning time f (ms)
POWER
Output power g, h (dBm)
Stability c
(dB)
Repeatability for a wavelength change
Signal to SSE g, i (dB)
±1 nm from peak with RBW 0.1 nm
Signal to total SSE (dB)
INTERNAL VARIABLE ATTENUATOR
Attenuation range (dB)
Linearity with attenuation (dB)
Repeatability for specific wavelength
k
Response time (s)
Notes
a. Specifications are valid at 23 °C ± 1 °C after one-hour warmup time.
b. FWHM: full width at half maximum. The specification is valid at 1580 nm, where
it corresponds to 12 pm.
Given in HR mode.
Typical 700 MHz at 1610 nm and 2 GHz at 1520 nm.
Linewidth is Gaussian-like and produces a coherence length of about 15 cm
when propagating into SMF-28 fiber type.
c. Expressed as ± half the difference between the maximum and
minimum values measured.
d. User calibration may be required.
e. Operating in continuous sweep.
Tunable Laser Source
I
b (GHz)
10 measurements
1 hour
Maximum
Minimum
From 1515 nm to 1610 nm
From 1510 nm to 1612 nm
15 minutes
1 hour
c
(dB) 10 measurements
From 1515 nm to 1610 nm
From 1550 nm to 1610 nm
c (dB)
MPORTANT
1510 to 1612
1
1.3 (typical)
±2.5 ( = 5)
±6 ( = 12)
±15
50
2
75 (typical)
0
—10
±0.005 ( = 0.01)
±0.01 ( = 0.02)
±0.015 ( = 0.03)
75 (typical)
80 (typical)
45
50 (typical)
10
±0.3 (typical)
±0.005 ( = 0.010) (typical)
)
0.5 (typical
f. 1 nm step, one complete step through GPIB in manual mode with FLS-2600B.
g. In normal mode. Operating in high-resolution mode (HR) typically reduces power level
at extreme wavelengths, therefore shortening the tuning range by a few nanometers.
h. At connector output of the source.
i. In the 1515 nm to 1610 nm range.
SSE: source spontaneous emission
RBW: spectral resolution bandwidth
j. ALC: Automatic level (or power) control.
k. For 1 dB step 10 % to 90 % response time.
