About this Manual:
This manual describes the installation and operation of the C-series/CVM1/CV-series Analog I/O Units
and includes the sections described below.
Please read this manual carefully and be sure you understand the information provided before attempting
to install and operate the Analog I/O Units.
Section 1 provides a general introduction on the Analog I/O Units.
Section 2 provides information on 3G2A5-AD001 to 3G2A5-AD005 Analog Input Units including the
specifications, connections, IR/CIO bit allocations, and applications.
Section 3 provides information on 3G2A5-AD006 and 3G2A5-AD007 Analog Input Units including the
specifications, connections, IR/CIO bit allocations, and applications.
Section 4 provides information on the C500-AD101 Analog Input Unit including the specifications, con-
nections, IR/CIO bit allocations, and applications for both two-word and four-word operation.
Section 5 provides information on the C500-AD501 Analog Input Unit including the specifications, con-
nections, IR/CIO bit allocations, and applications.
Section 6 provides information on 3G2A5-DA001 to 3G2A5-DA005 Analog Output Units including the
specifications, connections, IR/CIO bit allocations, and applications.
Section 7 provides information on the C500-DA101 Analog Output Unit including the specifications, con-
nections, IR/CIO bit allocations, and applications.
Section 8 provides information on the C500-DA103 Analog Output Unit including the specifications, con-
nections, IR/CIO bit allocations, and applications.
Section 9 provides information on the C500-DA501 Analog Output Unit including the specifications, con-
nections, IR/CIO bit allocations, and applications.
Appendix A provides DM memory and memory map coding sheets for the C500-AD101 Analog Input
Unit, the C500-AD501 Analog Input Unit, and the C500-DA501 Analog Output Unit. Appendix B provides
the dimensions of the Analog I/O Units.
WARNING
! Failure to read and understand the information provided in this manual may result in
personal injury or death, damage to the product, or product failure. Please read each
section in its entirety and be sure you understand the information provided in the section
and related sections before attempting any of the procedures or operations given.
