Omron SYSMAC C Series Operation Manual page 120

Specifications and General Information
6-1 Specifications and General Information
6-1-1 Specifications
General Specifications
Performance Specifications
106
All general specifications of the 3G2A5-DA001 through 3G2A5-DA005 Analog
Output Units conform to those of the C Series, except the following:
• Insulation between the External Terminals and the Frame:
5 MΩ min. at 250 VDC
• Breakdown Voltage between the External Terminals and the Frame:
500 VAC, 50-60 Hz for 1 minute
Item
Number of analog outputs
Output signal range p g g
Max. output current
External output impedance
Max. load resistance
Resolution
PC signal (See note 1)
Linearity error
Accuracy
Accuracy temperature coefficient ±50 PPM/°C
Conversion time (See note 2)
Conversion cycle
Words allocated
External connections
Power consumption
External dimensions
Weight
Note 1. A sign bit + 11 data bits binary data for Units with –10 to 10 V and –5 to 5 V
range.
2. Incorrect data results if the writing cycle is faster than the conversion time.
Specification
2
Voltage output g p
DA001 1 to 5 V
DA002 0 to 10 V
DA003 0 to 5 V
DA004 –10 to 10 V
DA005 –5 to 5 V
Current output DA001 4 to 20 mA
Voltage output 15 mA
0.5 Ω max.
Voltage output
550 Ω max.
Current output
1/4095 (full scale)
12-bit binary
±1/2 LSB max. (at 25°C)
±0.2% max. (full scale at 25°C)
5 ms max.
CPU Unit program cycle time
2 output words
17-pin terminal block (not removable)
550 mA max. at 5 VDC
34.5 x 250 x 113 mm (W x H x D)
600 g max.
Section 6-1
