Specifications and General Information
Current Outputs
BCD Data
Conversion data (unsigned BCD)
Conversion data (unsigned BCD)
140
0 to 20 mA Output
4 to 20 mA Output
The output specifications of the C500-DA501 Analog Output Unit with scaling
are shown below. Values between the scaling upper limit and lower limit are set
as conversion data in engineering units.
20 mA, 20 mA, 10 V, 5 V, 10V
4 mA, 0 mA, –10 V, 0 V, 0 V
Conversion Data Limits (in BCD or Binary Mode)
Limits
Setting range between scaling
upper limit and lower limit
Binary Data
0 to 20 mA Output
Conversion data (unsigned 12-bit binary)
4 to 20 mA Output
Conversion data (unsigned 12-bit binary)
Scaling
lower limit
BCD mode
–7999 to 7999
(F999 to 7999
Section
Scaling
upper limit
Binary mode
–32767 to 32767
) (8001 to 7FFF
Hex Hex
9-1
)
