Specifications and General Information

4-1-2 Description of Parts

Under the Cover
Front
Model label
Cover
30-pin ter-
minal block
Rear
Operating mode
setting switch
SW1: DIP switch to select input points
SW2: Toggle switch to read input range
Section 4-1
Four-word operation
Two-word operation
29
