Omron SYSMAC C Series Operation Manual page 21

Features
C500-DA101/103
C500-DA501
4
Output Specifications
The Units are compatible with a variety of output specifications. Select the ap-
propriate Unit from the table below.
Output signal range
Voltage g
Current
The C500-DA101 converts 12-bit binary data and the C500-DA103 converts
binary data with 1 sign bit + 11 data bits to analog output signals, with resolution
of 1/4095 in each case.
Number of Output Points Per Unit
Each Unit can handle D/A conversion for four output points.
A separate output signal range can be set for each C500-DA101 output point.
Output Specifications
The C500-DA101 can be set to one of the three output signal ranges shown in
the table below.
Output signal range
Voltage
Current
The C500-DA501 converts 12-bit binary/BCD data or binary/BCD data with 1
sign bit + 11 data bits to analog output signals, with resolution of 1/4095 in each
case.
Number of Output Points Per Unit
Each Unit can handle D/A conversion for eight output points.
A separate output signal range can be set for each C500-DA501 output point.
Output Specifications
Each output point for the C500-DA501 can be set to one of the output signal
ranges shown in the following table.
Output signal range
Voltage
Current
BCD or binary can be selected as the output data for each output point.
The scaling function can be set for each output point.
The upper/lower limit function can be set for each output point.
The output ramp function can be set for each output point.
High-speed D/A conversion can be set for all eight output points.
1 to 5 V
0 to 10 V
0 to 5 V
–10 to 10 V
–5 to 5 V
4 to 20 mA
1 to 5 V
0 to 10 V
–10 to 10 V
4 to 20 mA
0 to 10 V
0 to 5 V
–5 to 5 V
–10 to 10 V
0 to 20 mA
4 to 20 mA
Section 1-1
Unit
3G2A5-DA001
3G2A5-DA002
3G2A5-DA003
3G2A5-DA004
3G2A5-DA005
3G2A5-DA001
Unit
C500-DA101
C500-DA103
C500-DA101
Unit
C500-DA501
