Two-word Operation
(1 cycle ON)
A500
15
0100 0001
01 03
A500
06
(EQ)
0100
00
0100
01
0100 0001
01 03
A500
06
(EQ)
0100
02
0101
00
0101
01
0101
02
0101
03
0101
04
0101
05
0101
06
0101
07
Section 4-3
(030)
MOV #F0FF D00000
(030)
MOV #C000 D00001
(030)
MOV #0005 D00002
(030)
MOV #0010 D00003
(030)
MOV #0020 D00004
(030)
MOV #0050 D00005
(030)
MOV #0000 D00006
(030)
MOV #3000 D00007
(030)
MOV #1000 D00008
(030)
MOV #5000 D00009
(191)
WRIT #0010 D00000 0000
0100
00
0100
01
(190)
READ #0009 0001 D00100
0100
02
(030)
MOV D00108 0101
(101)
BCD D00100 D00300
(101)
BCD D00101 D00301
(101)
BCD D00102 D00302
(101)
BCD D00103 D00303
(101)
BCD D00104 D00304
(101)
BCD D00105 D00305
(030)
MOV D00106 D00306
(030)
MOV D00107 D00307
