Specifications And General Information; Specifications - Omron SYSMAC C Series Operation Manual

Specifications and General Information

7-1

Specifications and General Information

7-1-1 Specifications

General Specifications
Performance Specifications
116
All general specifications of the C500-DA101 Analog Output Unit conform to
those of the C Series.
Item
Number of analog outputs
Output signal range p g g
Max. output current
External output impedance
Max. load resistance
Resolution
PC signal
Overall accuracy
Conversion time (see note)
Words allocated
External connections
Isolation
Power consumption
External dimensions
Weight
Note The conversion time is defined as the time to convert the output data written to
the Analog Output Unit to full range (e.g., 1 to 10 V). Incorrect data results if the
writing cycle is faster than the conversion time.
Specification
4
Voltage output g p 1 to 5 V
0 to 10 V
Current output 4 to 20 mA
Voltage output 10 mA
0.5 Ω max.
Voltage output
400 Ω max.
Current output
1/4095 (full scale)
12-bit binary
±0.5% max. (full scale,
25°C
including linearity error)
±1.0% max. (full scale,
0 to 55°C
including linearity error)
10 ms max./4 words (also 1 word)
4 output words
17-pin terminal block (not removable)
Between output terminals and CPU Unit:
Photocoupler (no isolation between out-
puts)
1.3 A max. at 5 VDC
34.5 x 250 x 113 mm (W x H x D)
650 g max.
Section 7-1
