Data Exchange with CPU Unit
Words Bits Output
points
12 0 to 15
13 0 to 7 1 to 8
8 to 15 1 to 8
14 0 to 7 1 to 8
8 to 15 1 to 8
15 0 to 7 1 to 8
16 0 to 15 1 to 8
Name
Read Pointer Specifies the first RAM
address from which data is to
be read when the READ
instruction is executed from the
CPU Unit. It is set in the WRIT
instruction with the number of
words transferred set to 1.
Scaling Enable Set by the user to enable or
Bits disable the scaling for each
output point.
Output Ramp Set by the user to enable or
Enable Bits disable the output ramp for
each output point.
Upper/Lower Set by the user to enable or
Limit Enable disable the upper/lower limits
Bits for each output point.
BCD/Binary Set by the user to select either
Mode Bits BCD or binary data. The same
data format is used for all data
for each output point.
Conversion data: Addresses
01 to 08
Scaling upper and lower limits:
Addresses 17 to 32
Output ramp set time:
Addresses 33 to 40
Upper/lower limits: Addresses
41 to 56
Conversion Set by the user to enable or
Data Enable disable each output point.
Bits Conversion will be performed
for only the enabled output
points.
Conversion Set by the user to select the
Speed Mode conversion speed mode for all
Setting output points.
Description
0000 to 0061
(BCD)
ON: Enabled
OFF: Disabled
ON: Enabled
OFF: Disabled
ON: Enabled
OFF: Disabled
ON: BCD
OFF: Binary
ON: Enabled
OFF: Disabled
0000
FFFF
High-speed
Section
Data Default
Write: W
0000 (Pointer)
(BCD)
0 R/W
0 R/W
0 R/W
1 R/W
1 R/W
: Normal 0000 R/W
Hex Hex
:
Hex
9-3
Read: R
