Two-word Operation
CV/CVM1 Series
Programming Examples
48
IR 00108 through IR 00115 are used as Peak Flags. When the input point data
reaches a peak value, the flag corresponding to the input point will turn ON.
When both the Peak Read Bit and Peak Flags are ON, the peak value, which will
have been read at the last READ(87), will be written to DM 0200 through
DM 0207.
Because the CV/CVM1 Series offers higher processing speeds than the C Se-
ries, C Series programs may not run correctly if converted for the CV Series.
To use a program with the CV Series, the C500-AD101 Unconfirmed Data Flag
(CIO n+1, Bit 03) must be inserted as a execution condition for the WRIT instruc-
tion.
I/O bit
000103 C500-AD101 Unconfirmed Data
010000 Write Complete
010001 Write Complete Hold
010002 Read Complete
010100 Data 0 Disconnected
010101 Data 1 Disconnected
010102 Data 2 Disconnected
010103 Data 3 Disconnected
010104 Data 4 Disconnected
010105 Data 5 Disconnected
010106 Data 6 Disconnected
010107 Data 7 Disconnected
Function
Section 4-3
