4-1-3 Block Diagram

+Voltage/current
input
Input
–Current input
point 1
–Voltage/current
input
Shield
+Voltage/current
input
–Current input
Input
point 2
–Voltage/current
input
Shield
+Voltage/current
input
Input
–Current input
point 7
–Voltage/current
input
Shield
+Voltage/current
input
–Current input
Input
–Voltage/current
point 8
input
Shield
30
The following diagram shows the basic internal connections of the Unit.
Analog 0 V
Memory
Tim-
ing
Analog
DC/DC
power
converter
supply
Section 4-1
É É É
É É É
I/O
É É É
bus
Bus in-
terface
CPU
+5 V
0 V
