NOTE
NOTE
8. Enter the trigger count (Count), trigger delay time (Delay), trigger period
(Period), or trigger source (Trigger).
9. Press the rotary knob or assist key to fix the setting value.
10. Repeat steps 6 to 9 for all parameters.
If you want to set the trigger parameters in detail, select the MANUAL trigger type
and use the Trigger Configuration dialog box opened by pressing the Trigger >
Config function keys. See

To Set Source Wait Time

For details on this function, see
Control dialog box" on page
1. Press the Config > Common > Wait function keys.
The Wait Control dialog box opens.
2. Set each parameter in the Source column.
3. To apply the settings, press Apply.
To apply the settings and close the dialog box, press OK.
To cancel the setting change, press the Cancel/Local key.

To Set Output Filter

For details on this function, see
"Output Filter dialog box" on page
1. Press the Config > Source > Filter function keys.
The Output Filter dialog box opens.
2. Set each parameter.
3. To apply the settings, press Apply.
To apply the settings and close the dialog box, press OK.
To cancel the setting change, press the Cancel/Local key.
If you use an external filter, see
the dialog box properly.
Keysight B2961A/B2962A User's Guide, Edition 3
"Trigger key group" on page
"Measurement Time" on page 6-5
4-31.
"Output Filter and External Filter" on page 6-12
4-29.
"External Filter dialog box" on page 4-29
Front Panel Operations
To Set Source Output
4-35.
and "Wait
and set
and
5-17
