Table 6-6
Function Details

Initial Settings

Initial Settings
The B2961A/B2962A is initialized by turning the B2961A/B2962A on, the *RST
command, or the device clear. Initial settings are shown in this section.
System Initial Settings
Setup item
GPIO function
GPIO function (D14)
GPIO polarity
GPIO output trigger type
GPIO output trigger timing
GPIO output trigger pulse width
Zoomed display
Display image format
User message enable
User message
Byte swap (measurement data)
Data format (measurement data)
Data format (GPIO data)
Data format (status register)
Data elements (measurement data)
Data elements (calculate)
Automatic timestamp reset
Mass storage directory
6-34
Power on
DIGITAL IN
HIGH VOLTAGE LAMP
NEGATIVE
EDGE
BOTH
100 s
OFF
JPG
Disabled
""
OFF
ASCII
ASCII
ASCII
All (V/I/R/S/T/Stat)
CALC
ON
(Root)
Keysight B2961A/B2962A User's Guide, Edition 3
Reset






Not changed











