Program key group

Pressing the Program key displays the following softkeys for setting and controlling
the program memory.
The program memory can be defined by using the SCPI commands while the
B2961A/B2962A is in the remote mode.
Displays the Program Catalog dialog box which lists the programs saved in the
program memory. This dialog box is also used to specify the memory program to
use. To select a memory program, highlight its name in this list.
Displays the Program View dialog box which shows the program code of the
specified program.
Displays the Variable dialog box which lists the variables used in the memory
programs. Available index is 1 to 100.
Displays the following softkeys for controlling the operation of the program
memory.
Run Starts the specified memory program.
Pause Pauses the execution of the memory program.
Step Starts the step execution of the specified memory program.
Stop Stops the execution of the memory program.
Continue Continues the execution of the memory program presently
paused.
Keysight B2961A/B2962A User's Guide, Edition 3
Front Panel Reference
Program key group
4-41
