CAUTION
• Auto key
Starts a repeat (continuous) measurement. If a repeat measurement is in
progress, stops it.
The repeat measurement is performed with the DC bias output of the Source
value. And the measurement result is displayed on the Single view or Dual view.
The repeat measurement result is not stored in the buffer.
• USB-A connector
Used to connect a USB memory. After disconnecting the USB memory, wait 10
seconds before connecting it again or new one.
Turning the instrument off while the USB memory is being accessed may damage
the device.
• Function keys
Six function keys are available below the display. They are assigned to the
softkeys, Config, Function, Trigger, Result, File, Program, I/O, Display, System,
and More. For details, see
• Assist keys
Five assist keys are available to the right of the display. They are assigned to
several softkeys, such as Mode, Source, Limit, Measure, and More. The softkey
assignment depends on the display mode (Single, Graph, or Dual). For details,
see Chapter 4, "Front Panel Reference."
• View key
Changes the display mode. Pressing the key changes the mode as shown below.
On B2961A
On B2962A
• Cancel / Local key
Cancels the setup operation if the instrument is in the local status. Returns the
instrument to the local status if it is in the remote status.
Keysight B2961A/B2962A User's Guide, Edition 3
Chapter 4, "Front Panel Reference."
Single  Graph  (return to Single)
Dual  Single for channel 1  Single for channel 2 
Graph  (return to Dual)
Introduction
Front View
2-5
