Front Panel Reference

File key group

File key group
Pressing the File key displays the following softkeys for saving a file on and loading
a file from a USB memory connected to the front panel USB-A connector.
Displays the following softkeys for saving a file. Pressing a softkey displays the File
Selection dialog box. See
Measure Saves a measurement data file.
Math Saves a math result data file.
Trace Saves a trace buffer data file.
Config Saves a system setting data file.
Displays the following softkey for loading a file. Pressing the softkey displays the
File Selection dialog box. See
Config Loads a system setting data file.

File Selection dialog box

This dialog box provides the following GUI for saving or loading a file.
Path Folder name for saving or loading a file.
File Name File name to save or load.
The files and folders saved in the specified folder are listed in the area between the
Path field and the File Name field. This area can be used for selecting a file by
highlighting its name.
For saving a system setting file, if the file extension is not specified, ".sta" is added
automatically. For saving the other data file, ".csv" is added automatically.
4-40
"File Selection dialog box" on page
"File Selection dialog box" on page
Keysight B2961A/B2962A User's Guide, Edition 3
4-40.
4-40.
